6.3 Switching off the engine
Before you switch off the generator, allow it to run
briefly with no consumers so that it can “cool
down”
Move the ON/OFF switch (7) to position “0”
Turn the petrol cock (4) to position “0”.
Important. The generator is fitted with an overlo-
ad cut-out.
This shuts down the 230V~ socket (3). You can
restart the socket (3) by pressing the overload cut-
out (6).
Important. If this happens, reduce the electric
power you are taking from the generator.
6.4 Connecting to earth
The generator must be earthed to prevent an electric
shock from electrical equipment. Connect a piece of
cable between the earth connection on the generator
and an external earth point.
7. Maintenance
Remove dust and dirt from the machine at regular
intervals. The best tools for cleaning are a fine
brush or a cloth
Do not use any caustic substances to clean the
plastic
Take the petrol mixture out of the generator if you
do not intend to use the generator for a lengthy
period of time
Important. Switch off the machine immediately
and contact your service station:
In the event of unusual vibrations or noise
If the engine appears to be overloaded or misfires
If the emissions are too dark or too light
8. TECHNICAL DATA
Generator Synchronous
Protection type IP 23
Continuous power S1 650 VA / 650 W
Maximum power S2 15 min. 800 VA / 800 W
Rated voltage 230 V / 1
Rated current 2.8 A / 1
Frequency 50 Hz
Drive engine design 1-cyl. 2-stroke, air-cooled
Displacement 63 cc
Max. power 0.95 KW / 1.3 hp
FuelMixture 1:50 (2%)
Tank capacity 4.0 l
Consumption at 3/4 load approx. 0.7 l/h
Weight 20.5 kg
Sound power level LWA 92 dB(A)
Sound pressure level LWM 88 dB(A)
Spark plug: NGK BPR5ES
GB
6
