EKF MASTER M830B - Direct Current

5
Range Resolution Accuracy
200 mV
0,1 mV ± 0,5% ± 3D
2000 mV 1 mV
± 0,8% ± 5D20 V 10 mV
200 V 0,1 V
1000 V 1 V ± 1,0% ± 5D
Range Resolution Accuracy
200 V 0,1 V
± 2,0% ± 10D
750 V 1 V
Range Resolution Accuracy Model
200 µA 0,1 µA
±1,8%
± 2D
M830B
2000 µA 1 µA
M830B,
M832, M838
20 mА 10 µA
M830B,
M832, M838
200 mА 0,1 mА ±2% ± 2D
M830B,
M832, M838
10 А 10 mА ±2% ± 10D M832, M838
DC VOLTAGE
AC VOLTAGE
DIRECT CURRENT
*D - least signicant digit value
Overload protection: 220 V
Root-mean-square value (RMS)
for 200 mV and 1000 V DC range or 750 V
(RMS) for all other ranges.
Overload protection:
1000V DC or 750 V DC/AC (RMS)
Frequency: 45 - 450 Hz.
Measurement of the mean
value equal to the RMS value (RMS)
for sinusoidal signals.
Overload protection: fuse 500 mA/250 V.
(The range 10 A is not protected against
overloading).
RESISTANCE
TEMPERATURE
Range Resolution Accuracy
200 Оhm 0,1 Оhm ±1,0% ± 10D
2000 Оhm 1 Оhm
±1,0% ± 4D
20 kOhm 10 Оhm
200 kOhm 0,1 kOhm
2000 kOhm 1 kOhm
Range Resolution Accuracy
from -40°С to +150°С
1°С
±1,0% ± 4D
from +150°С to
+1370°С
±1,5% ± 15D
Maximum open circuit voltage: 3,2 V.
Overload protection: 15 s, 220 V DC/ AC
(RMS)
Function Description
Diode test Indicates the direct voltage drop in the diode
Transistor test Range: 0 - 1000; Test current Ibase = 10 μA; Test voltage Vce = 2,8 V
Circuit continuity test
(buzzer)
If the resistance of the tested circuit is less than 30 ± 20 Ohm, the
buzzer sounds. Overload protection: 15 s, 220 V DC/AC (RMS)
Signal generation with
50 Hz frequency (square
signal)
Input voltage 5 V, 50 kOhm
OTHER FUNCTIONS
