The overall dimensions are shown in tables 2-5. For manufacturer,
refer to the package.
Table 2 – Overall dimensions of wall-mounted distribution
enclosures EKF PROXIMA by OOO «Electroresheniya»
Parameters Values
Rated voltage, V 230 / 400
Rated current, A 100A
Enclosure material Plastic
Enclosure colour White
Method of installation
Wall-mounted /
Flush-mounted
Degree of protection in compliance with IEC 60529 IP41
Name
Quantity
of modules
Net weight, kg
HхWхD
(enclosure),
mm
Wall-mounted plastic distribution enclosure 3 3 0,467
150х60х95
Wall-mounted plastic distribution enclosure 4 4 0,467
200х112х95
Wall-mounted plastic distribution enclosure 6 6 0,497 200х148х95
Wall-mounted plastic distribution enclosure 8 8 0,613 200х184х100
Wall-mounted plastic distribution enclosure 10 10 0,735 200х222х100
Wall-mounted plastic distribution enclosure 12 12 0,76 200х256х100
Wall-mounted plastic distribution enclosure 15 15 0,9 200х312х95
Wall-mounted plastic distribution enclosure 18 18 1,24 200х362х100
Wall-mounted plastic distribution enclosure 24 24 1,49 327х256х100
Wall-mounted plastic distribution enclosure 36 36 2,14 460х270х100
Wall-mounted plastic distribution enclosure 45 45 2,2 470х325х100
1 DESCRIPTION
The wall/ush-mounted plastic distribution enclosures IP41 EKF PROX-
IMA are intended for installation of modular DIN rail products: miniature
circuit breakers, residual current devices, timers, electricity meters etc.
2 TECHNICAL DATA
The technical performances are given in table 1.
Table 1
