7
Table 3 continued
Parameters
Values
Rated operating voltage Ue, V
АС
400 V
АС
690 V
АС
400 V
АС
690 V
Min. mechanical endurance, O-C cycles 2500 2500
Min. electrical endurance, O-C cycles 1500
Rated peak short-circuit current Icm, kA 2,2хIcu
Rated insulation voltage Ui, V 800
Utilization category according
to IEC 60947-2:2016
А
Type of trip unit Thermal-magnetic
Set point of electromagnetic trip unit 10хIn
Number of poles (standard) 3P
Power consumption, W 160 160
Protection degree IP30
Operating temperature, °C from – 25 to + 40
Weight, kg 26,8
Min. service life, years 10
