ELA Aviacion ELA 10-Eclipse - 3.8 Limitations Tables

ELA 10-Eclipse PILOT OPERATOR´S
HANDBOOK
Version: V10-05
Issue date: 26
th
July 2016.
Last modification: 04
th
February 2019.
32
3.8 LIMITATIONS TABLES
* See MTOW limitation for your country
Data
Caution
Normal
Caution
Max
Speed
0 – 80 kph
0 – 50 mph
0 – 45 kts
80 – 160 kph
50 – 100 mph
45 – 86 kts
160 – 180 kph
100 – 112 mph
86 – 97 kts
190 kph<
119 mph<
103 kts<
Rotor speed (rpm)
*300
300 - 500
500 - 560
560<
Engine speed (rpm)
0 - 1400
1400 - 5500
5500 - 5800
5800<
Oil temp
<90ºC
<194 ºF
90 – 110ºC
194 – 230ºF
110 – 130ºC
230 – 265ºF
130ºC<
265ºF<
Oil press
0 – 2 bar
0 – 30 psi
2 – 5
30 – 75 psi
5 – 7
75 – 100 psi
7 bar<
100 psi<
CHT
<60ºC
<140ºF
60 – 110ºC
140 – 230ºF
110 – 120ºC
230º - 250ºF
120ºC<
250ºF<
Man. press. 912 ULS (in.HG)
-
0 – 27
27<
-
Man. press. 914 UL (in.HG)
-
0 – 35
35 – 39
39<
* Max. Pre-rotator speed: 300 rpm.
DATA
LIMITATION
Take-off weight (MTOW) 912 ULS engine
*Take-off weight (MTOW) 914 UL engine
500 kg (1100 lb)
530 kg (1170 lb)
Pilot weight (front)
55 – 110 kg
130 – 240 lb
Load factor
+3.5g
Bank angle
60º
Ambient temperature
-20 – 40ºC
-4 – 105ºF
Turbulence speed (Vb)
105 kph
65 mph
57 kts
Wind or gust
40 kts
Cross wind take-off and landing
15 kts
Tail wind landing
5 kts
