ELA 10-Eclipse PILOT OPERATOR´S
HANDBOOK
Version: V10-05
Issue date: 26
th
July 2016.
Last modification: 04
th
February 2019.
34
Operating limitations: Placard in clear view to pilot and co-pilot. It is placed
between the front and the rear seats, at the left side of the cockpit.
ELA 10-Eclipse 912 ULS
OPERATING LIMITATIONS
Aerobatic manoeuvres are prohibited.
Manoeuvres involving a deliberate reduction in normal ‘g’ shall be avoided.
CG Range Limits (Gyroplane) – refer to Pilot Operator´s Handbook.
Maximum Indicated Airspeed (Vne): 190 kph (119 mph/103 kts)
This aircraft shall be flown by day and under Visual Flight Rules only.
Smoking in the aircraft is prohibited
AIRCRAFT PAYLOAD SPECIFICATION
Front seat pilot weight: 55 – 110 kg (130 – 240 lb)
Rear seat pilot max. weight: 110 kg (240 lb)
In solo flight, the pilot should be seated in the front position
MTOW: 500 kg (1100 lb)
ELA 10-Eclipse 914 UL
OPERATING LIMITATIONS
Aerobatic manoeuvres are prohibited.
Manoeuvres involving a deliberate reduction in normal ‘g’ shall be avoided.
CG Range Limits (Gyroplane) – refer to Pilot Operator´s Handbook.
Maximum Indicated Airspeed (Vne): 190 kph (119 mph/103 kts)
This aircraft shall be flown by day and under Visual Flight Rules only.
Smoking in the aircraft is prohibited
AIRCRAFT PAYLOAD SPECIFICATION
Front seat pilot weight: 55 – 110 kg (130 – 240 lb)
Rear seat pilot max. weight: 110 kg (240 lb)
In solo flight, the pilot should be seated in the front position
MTOW: 530 kg (1170 lb)
