ELA DD822 - Technical Data; Plug Wiring Instructions

Wiringfora13Ampplug(BS1363)
TheEarthTerminalismarkedwith
theletterEorEarthSymbol
BS Plug Wiring
Wiring Instructions: Should it be necessary to change the plug please note
thewiresinthemainsleadarecolouredinaccordancewiththefollowing
code:
BLUE‐ NEUTRAL
BROWN‐ LIVE
GREEN/YELLOW‐ EARTH
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
1. The BLUE wire is the NEUTRAL and must be connected to the terminal
that is marked with the letter N or coloured BLACK.
2. The BROWN wire is the LIVE andmustbeconnectedtotheterminalthat
is marked with the letter L or coloured RED.
3. Neither wire is to be connected to the terminal which is marked with the
letter E or earth symbol , coloured GREEN or GREEN/YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fusedplugisuseditmustbefittedwitha13A (BS 1362)
fuse. If in doubt consult a qualified electrician.
TECHNICALDATA
10
