Elation PALADIN Panel - DMX Channel Functions and Values

22
DMX CHANNEL FUNCTIONS AND VALUES
ELATION PALADIN PANEL™
RGB MODES - DMX Channel Values / Functions (88 Total DMX Channels)
Supports Software Versions: ≥ 1.0.1
Features subject to change without notice.
*Pixel Zone Control depends on DMX Mode, Flip setting, and fixture head tilt position.
RGB
3CH
8bi
4CH
16bit
8CH
16bit
Dim
10CH
Extended
16CH
Cells
80CH
Cells
Dim
82CH
Ext-Cells
88CH
Value
Function
Default
Snap
1
1
Strobe
50
X
0-31
Closed
32-63
Open
64-95
Strobe (slow → fast)
96-127
Open
129-159
Pulse (slow → fast)
160-191
Open
192-223
Random (slow → fast)
224-255
Open
1
2
1
2
Master Intensity
0
0-255
Close → Open
2
3
2
3
Master Intensity Fine
0
0-255
Close → Open
