Elation PALADIN Panel - Page 32

32
HSI 4CH
HSI-Ext
10CH
HSI-Cell
38CH
Value
Function
Default
Snap
5
5
Control
0
X
0 -19
Idle
20-24
Program 1
25-29
Program 2
30-34
Program 3
35-39
Program 4
40-44
Program 5
45-49
Program 6
50-54
Program 7
55-59
Program 8
60-64
Program 9
65-69
Program 10
70-74
Program 11
75-79
Program 12
80-100
Idle
Change Refresh Rate (Hz)
(Hold 1s)
101 - 105
900
106 - 110
1000
111 - 115
1100
116 - 120
1200 (default)
121 - 125
1300
126 - 130
1400
131 - 135
1500
136 - 140
2500
141 - 145
4000
146 - 150
5000
151 - 155
10000
156 - 160
15000
161 - 165
20000
166 - 170
25000
171-200
Idle
Dimmer Curves
(Hold 3s)
201-210
Linear (default)
211-220
Square
221-230
Inverse Square
231-240
S-Curve
241-255
Idle
