XPT/R2G
Pag. 18
1 19kHz sync. Out ( 1 Vpp )
2 Ext.Carrier Enable (closed=off)
3 Alarm1 contact out
4 Alarm 2 contact out
5 GND
6 NC
7 NC
8 NC
13 IN/OUT
PIN
NUMBER
( DB9 )
9 NC
1 NC
2 Input RS485+
3 Input RS485-
4 NC
5 GND
6 NC
7 NC
8 NC
14
COM3B
RS485
PIN
NUMBER
( DB9 )
9 NC
1 NC
2 Input RS485+
3 Input RS485-
4 NC
5 GND
6 NC
7 NC
8 NC
16
COM3A
RS485
PIN
NUMBER
( DB9)
9 NC
1 NC
2 RX
3 TX
4 NC
5 GND
6 NC
7 NC
8 NC
17
COM2
RS232
PIN
NUMBER
( DB9)
9 NC
1 ALL1
2 ALL2
3 GND
4 Direct Power
5 Reflected Power
6 -12V
7 +15V
8 Modulation meter
18 AUX IN/OUT
For analog remote monitoring
PIN
NUMBER
( DB9)
9 NC
19 GND - EARTH
20 LINE FUSE 1AT for 230Vac 2AT for 115Vac
21 RF Monitor (10dBm for 2W output)
