1.Overview
Rail‐mounted multi‐circuit power meter can measure parameters of multiple three phase or
single phase power grid such as voltage, current, power, frequency, energy, demand, extreme
value, total harmonic distortion, 2nd‐31st harmonics, voltage and current unbalance and
multi‐rate electric energy measurement. The maximum measurement circuits of PD194Z‐E14 is
four three‐phase circuits or twelve one single‐phase circuits. The meter adopts access mode of
external current transformer and modular design which is convenient for user to choose
different functions to meet different requirements at field.
2.Functions
The table below lists correlated variables the meter can measure including variables obtained
through basic power and further calculations.
Measuring function
Accuracy
Real
time
Extreme
value
Demand
Remarks
Phrase voltage, wire voltage
0.2
●
●
—
Voltage
0.2
●
●
●
Frequency
±0.01Hz
●
●
—
Phase active power
0.5
●
●
●
Total active power
0.5
●
●
●
Phase reactive power
0.5
●
●
—
Total reactive power
0.5
●
●
—
Phase apparent power
0.5
●
●
—
Total apparent power
0.5
●
●
—
Phase frequency factor
0.5
●
●
—
Total power factor
0.5
●
●
—
Total harmonic distortion
A grade
●
2‐31 harmonic distortion
A grade
●
Input/output active energy
0.5S
●
—
—
Closed type
current
Input/output reactive energy
2
●
—
—
transformer:0.5
S grade; Open
type current
Multi‐rate active energy
0.5S
●
