Electraline 59007 - AC Voltage Specifications; DC Current Specifications; Resistance Specifications

AC VOLTAGE
RANGE ACCURACY RESOLUTION
200V
±(1.2% of rdg+10D)
100mV
250V 1V
OVERLOAD PROTECTION: 250V DC or 250V rms for all ranges.
DC CURRENT
RANGE ACCURACY RESOLUTION
200 μA
±(1.8% of rdg +2D)
100nA
2000 μA 1 μA
20mA 10 μA
200mA
±(2.0% of rdg +2D)
100 μA
10A
±(2.0% of rdg +10D)
10 mA
RESISTANCE
RANGE ACCURACY RESOLUTION
200 Ω ±(1.0% of rdg +10D) 0.1 Ω
2000 Ω
±(1.0% of rdg +2D)
1 Ω
20 K Ω 10 Ω
200 K Ω 100 Ω
2000 K Ω 1 K Ω
TEST DIODE
RANGE DESCRIPTION
The forward voltage drop in mV will be displayed. (Test voltage: 2.8V )
75$16,6725K)(0($685(0(17
RANGE TEST RANGE TEST CURRENT TEST VOLTAGE
NPN/PNP 0-1000 I b=10μA Vce=2.8V
RESPONSE: Average responding, calibrated
in rms of a sine wave.
FREQUENCY RANGE: 45Hz ~ 450Hz
OVERLOAD PROTECTION: 0.5A/250V
and 10A/250V fuse
MEASURING VOLTAGE DROP: 200mV
MAXIMUM OPEN CIRCUIT VOLTAGE: 3.0V.
OVERLOAD PROTECTION: 15 seconds
maxi- mum 220Vrms.
