ELECTRO FREEZE Model CS4
184964-04 Use only original or authorized replacement parts with this freezer 9
123456789012345
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
1
2345678901234
5
123456789012345
Figure 8 Model CS4 – Assembly (Sheet 2 of 2)
Item Part No. Description
23 119313 Box-Assy Capacitor & Componets
(See Figure 5)
24 119138-C Panel-Assy. Hopper & Top includes
161300 Switch-Level Float Sensor
25 161301 Float-Level Sensor
26 161300 Switch-Level Float Sensor
27 116021 Tube-Assy. Mix Feed (See Figure 3)
28 114341-06 Stud-Assy. Cylinder 2-1/16”
29 118162 Drain-Assy. Overflow
30 119279 Compressor-Assy. includes compressor
and
151421 Capacitor-Run
151445 Capacitor-Start
155063 Drier-Filter 3 cu. in. Sweat
151444 Relay-Compressor
(See Figure 5 for Capacitor/Relay Box)
31 115800 Leg-Assy. (Optional)
32 162625 Knob-Hand
33 196203 Trimstrip
34 150541 Light-Indicator 28v ADD MIX
35 138261 Panel-Dispense w/o Lights (United
Kingdom)
137772 Panel-Dispense (Italy)
36 115696-01-C Panel-Assy. Front (United Kingdom)
115696-C Panel-Assy. Front (Italy)
37 196204 Tray-Drip
38 196205 Insert-Drip Tray
39 119199 Head-Assy. Dispense w/Stainless Steel
Handle (See Figure 1)
40 115789 Cover-Assy. Electric Box
Not Shown:
161216 Sensor-10K Thermistor
150279 Transformer-Cntrl 24VAC 130VA
155419 Valve-Access
1 118137 Kit-Motor & Capacitors 3/4 HP (Beater Motor)
includes motor and
150233 Capacitor-Start
150234 Capacitor-Run
(See Figure 5 for Capacitor/Relay Box)
2 153639 Sheave-5/8 Bore 2.00 OD (Driver Pulley)
2A 160495 Screw-SK Set 1/4-20 x 1/4 BKOX
3 153638 Sheave-1 Bore 12.25 OD (Driven Pulley)
3A 160033 Screw-SK Set 5/16-18 x 3/8 BKOX
4 153177 Belt-V
5 153322 Key-Drive 3/16" Sq. x 1 1/2"
6 153323 Key-Drive 1/4" Sq. x 1 1/2"
7 119016 Control-Assy. & Bracket (Thermostat) includes
139920 Bracket-Thermostat
161218 Control-Electronic Temperature
Dual
8 119017-01 Potentiometer-Assy. & Bracket includes
150199 Potentiometer-Trimmed 0-451 OHM
9 155470 Valve-Solenoid 1/4ODF 24VAC
10 139924 Tube-Capillary w/Strainer
11 155450 Cut Out-High Pressure
12 137787 Cap-Coupling
13 153030 Bearing-1” Pillow Block
14 115767 Shaft-Assy. Drive includes drive shaft and
137787 Cap-Coupling
160056 Screw-SK Set 1/4-20x1/4 ZN
15 155452 Valve-Auto Expansion Sweat
16 155459 Glass-Sight
17 155063 Drier-Filter 3 cu. in. Sweat
18 155126-01-C Condenser-Air Rifled
19 137739 Shroud-Fan
20 151080 Motor-Fan 35W 230-1-50/60
21 159018 Blade-Fan 10 in. 32º
21A 160104 Nut-Hex 1/4-20 ZN (Fan Blade)
22B 162611 Bracket-Fan Motor
Item Part No. Description
Item Part No. Description
Model CS4 - Assembly
