Table 2-2: Toggle Switches and Their Functions
Label Function
Pattern Switch 1 Programs a 1 or 0 for pattern bit 1
Pattern Switch 2 Programs a 1 or 0 for pattern bit 2
Pattern Switch 3 Programs a 1 or 0 for pattern bit 3
Pattern Switch 4 Programs a 1 or 0 for pattern bit 4
Pattern Switch 5 Programs a 1 or 0 for pattern bit 5
Pattern Switch 6 Programs a 1 or 0 for pattern bit 6
Pattern Switch 7 Programs a 1 or 0 for pattern bit 7
Pattern Switch 8 Programs a 1 or 0 for pattern bit 8
Pattern Switch 9 Programs a 1 or 0 for pattern bit 9
Pattern Switch 10 Programs a 1 or 0 for pattern bit 10
Pattern Switch 11 Programs a 1 or 0 for pattern bit 11
Pattern Switch 12 Programs a 1 or 0 for pattern bit 12
Pattern Switch 13 Programs a 1 or 0 for pattern bit 13
Pattern Switch 14 Programs a 1 or 0 for pattern bit 14
Pattern Switch 15 Programs a 1 or 0 for pattern bit 15
Pattern Switch 16 Programs a 1 or 0 for pattern bit 16
Gate Bus Switch 1 Directs signal to Gate Bus 1, 2 or 3 from Step 1
Gate Bus Switch 2 Directs signal to Gate Bus 1, 2 or 3 from Step 2
Gate Bus Switch 3 Directs signal to Gate Bus 1, 2 or 3 from Step 3
Gate Bus Switch 4 Directs signal to Gate Bus 1, 2 or 3 from Step 4
Gate Bus Switch 5 Directs signal to Gate Bus 1, 2 or 3 from Step 5
Gate Bus Switch 6 Directs signal to Gate Bus 1, 2 or 3 from Step 6
Gate Bus Switch 7 Directs signal to Gate Bus 1, 2 or 3 from Step 7
Gate Bus Switch 8 Directs signal to Gate Bus 1, 2 or 3 from Step 8
Gate Bus Switch 9 Directs signal to Gate Bus 1, 2 or 3 from Step 9
Gate Bus Switch 10 Directs signal to Gate Bus 1, 2 or 3 from Step 10
Gate Bus Switch 11 Directs signal to Gate Bus 1, 2 or 3 from Step 11
Gate Bus Switch 12 Directs signal to Gate Bus 1, 2 or 3 from Step 12
Gate Bus Switch 13 Directs signal to Gate Bus 1, 2 or 3 from Step 13
Gate Bus Switch 14 Directs signal to Gate Bus 1, 2 or 3 from Step 14
Gate Bus Switch 15 Directs signal to Gate Bus 1, 2 or 3 from Step 15
Gate Bus Switch 16 Directs signal to Gate Bus 1, 2 or 3 from Step 16
Merge 1 Switch Merges Gate Bus 1 adjacent gates and triggers
Merge 2 Switch Merges Gate Bus 2 adjacent gates and triggers
Merge 3 Switch Merges Gate Bus 3 adjacent gates and triggers
Bus 1 Load Switch Enables pattern re-load when Bus 1 transitions to high
Clock Enable Switch Connects/Disconnects clock input
Rand/Pat Switch Switches between random and programmed pattern mode
8X2/16X1 Switch Switches between two 8 stage patterns or one 16 stage pattern
Invert B Switch Enables inversion of Register B recirculated data
Optional External
Load Enable
Enables/Disables the external load signal applied to the External
Load Jack
