Label Function
Optional
External/Internal
Range Switch
Selects between an applied external voltage and an internal
variable range voltage to be applied as the maximum range of the
programming pots.
Total Number of Toggle Switches: 40 Standard, 2 more with available Options
Table 2-3: Momentary Pushbutton Switches and Their Functions
Label Function
Manual Load Loads programmed pattern into shift register
Manual Step Advances shift register one step with each key press
Total Number of Momentary Pushbutton Switches: 2
Table 2-4: Rotary Switch and Its Function
Label Function
Range Selects maximum range of programming pots (eight position)
Total Number of Rotary Switches: 1
Table 2-5: Jacks and Their Functions
Label Function
A Output Outputs voltage pattern generated by section A (first 8 stages)
B Output Outputs voltage pattern generated by section B (second 8 stages)
A+B Output Outputs summed A+B pattern signal (all 16 stages)
Master Gate Outputs constant gate signal synchronous with clock
Master Trigger Outputs constant trigger signal synchronous with clock
Bus 1 Gate Outputs Gate Bus 1 gate signal
Bus 1 Trigger Outputs Gate Bus 1 trigger signal
Bus 2 Gate Outputs Gate Bus 2 gate signal
Bus 2 Trigger Outputs Gate Bus 2 trigger signal
Bus 3 Gate Outputs Gate Bus 3 gate signal
Bus 3 Trigger Outputs Gate Bus 3 trigger signal
Clock Input Accepts clock signal
External Load In Accepts pulse signal to initiate pattern load on rising edge
Random In Accepts signal from which random patterns are generated
Optional A Output Outputs voltage pattern generated by section A (first 8 stages)
Not affected by Glide Control A
Optional Aux B
Output
Outputs voltage pattern generated by section B (second 8 stages)
Not affected by Glide Control B
Optional Aux A+B
Output
Outputs summed A+B pattern signal (all 16 stages)
Not affected by Glide Control
Optional Variable
Range Input
Accepts an external positive voltage input and applies that voltage
as the maximum programming pot range.
Total Number of Jacks: 14 standard, 4 more available as options.
7
