way systems – for down fill, far throw, delay
rings, under balcony and low-frequency
enhancement.
Many of the two-way systems also provide
superb performance on their own when room
acoustics and geometry are appropriate.
When performance demands are high,
Xi-Series
™
, in combination with Merlin
®
signal
processing, will find ideal application in
performing arts centers, theaters, auditoriums,
houses of worship and regional touring.
Carrying handles on each
side of all Xi-Series
™
enclosures
Specially designed
multigrip handles
are extremely
comfortable and can be
gripped from any angle,
making lifting much easier.
The large sys-
tems feature
four handles
per side, and
the compact
two-way
systems have
two handles
per side. (The
ultracompact Xi-1082 under-
balcony system has no
han
dles.)
Power: Unrivaled fidelity
at high outputs
Electro-Voice
Precision Series
™
power amplifiers
perfectly complement
Xi-Series
™
and are on tour with
the Rolling Stones and their
X-Array
™
X-Series
™
system.
Precision Series
™
amplifiers
exhibit very high peak output
for uncompromised fidelity at
Signal processing
support
Full system configuration
parameters are available for
crossover, signal delay,
parametric EQ and compres-
sion/limiting functions in
the following products:
• Merlin
®
ISP-100
• Klark Teknik DN8000
• Electro-Voice Dx34A
Before Xi-Series
™
and Merlin
®
(conventional
crossover).
high sound levels (140 volts
peak — nearly 2,500 watts into
8 ohms — for the P3000; 110
volts peak — over 1,500 watts
— for the P2000). Dual power
supplies allow driving subs and
mid- or high-channels from the
same amplifier, without signal
degradation.
The winning combination of Xi-Series
™
and Merlin
®
ISP-100 offers substantial
increases in system intelligibility in
reverberant spaces. See page 7 for more
Merlin
®
details.
Two- and three-element line arrays
After Xi-Series
™
and Merlin
®
(“tripole” config-
uration). Note dramatically increased directiv-
ity at mid/low frequencies.
1 Top woofer slot
2 Mid-bass horn mouth
3 Bottom woofer slot
PAGE 3
The “tripole” configuration of the
Xi-2153/64 and Xi-2123/106 allows
output from the mid-bass horn to join
that of the spaced, dual low-frequency
sources and provide exceptional vocal
clarity in rever-berant spaces and
resistance to feedback beneath the
loudspeaker. This is accomplished
by extending a precisely controlled
radiation pattern to unusually low
frequencies.
