Full-Range Three-Way Systems
System: Xi-1123/106 Xi-2123/106 Xi-1153/64 Xi-1183/64 Xi-2153/64 Xi-2183/64
Frequency Response: 60-20,000 Hz 60-20,000 Hz 48-20,000 Hz 45-20,000 Hz 48-20,000 Hz 45-20,000 Hz
Crossover Frequencies: 250/550 Hz, 1,760 Hz 250/550 Hz, 1,760 Hz 125/540 Hz, 1,760 Hz 125 Hz, 1,760 Hz 125/540 Hz, 1,760 Hz 125 Hz, 1,760 Hz
Power Handling, Long Term: 300/300/75 W, 300/300W 600/300/75 W, 600/300W 600/300/75 W 600/300/75 W 1,200/300/75 W 1,200/300/75 W
Sensitivity (1 W/1 m), Triamp: 98.0/109.0/111.7 dB 101.4/109.0/111.7 dB 91.5/107.0/112.0 dB 93.5/107.0/112.0 dB 96.0/107.0/112.0 dB 98.0/107.0/112.0 dB
Biamp/FR: 101.4/106.7 dB 101.4/106.7 dB N/A N/A N/A N/A
Nominal Coverage Angle (H x V):100°x 60° 100°x 60° 60°x 40° 60°x 40° 60°x 40° 60°x 40°
Dipole/Tripole Configurable
(with Merlin
®
ISP-100): Yes Yes Yes No Yes No
Excursion-Smart Protection
(with Merlin
®
ISP-100): Yes (biamp mode only) Yes (biamp mode only) No No No No
Transducers, LF: DL-type 12-inch Two DL-type 12-inch EVX-155 15-inch EVX-180B 18-inch Two EVX-155 15-inch Two EVX-180B 18-inch
MB: DL-type 10-inch mid-bass DL-type 10-inch mid-bass 12-inch mid-bass 12-inch mid-bass 12-
inch mid-bass12-inch mid-bass
on 100°x 60°rotatable horn on 100°x 60°rotatable horn on mid-bass horn on mid-bass horn on
mid-bass hornon mid-bass horn
HF: DH6-16 (1.4-in. exit) DH6-16 (1.4-in. exit) DH6-16 (1.4-in. exit) DH6-16 (1.4-in. exit) DH6-16 (1.4-in. exit) DH6-16 (1.4-in. exit)
on 100°x 60°rotatable horn on 100°x 60°rotatable horn on 60°x 40°rotatable horn on 60°x 40°
rotatable hornon 60°x 40°rotatable horn on 60°x 40°rotatable horn
Impedance, LF-FR/MB/HF: 12/16/16 ohms 6/16/16 ohms 8/16/16 ohms 8/16/16 ohms 4/16/16 ohms 4/16/16 ohms
Connectors: Two Neutrik NL8MPR Two Neutrik NL8MPR Two Neutrik NL8MPR Two Neutrik NL8MPR Two Neutrik NL8MPR Two Neutrik NL8MPR
Recommended Power Amp (watts @
8 ohms), LF/MB/HF: 600/600/600 W 600/600/600 W 800/800/600 W 800/800/600 W 800/800/600 W 800/800/600 W
Passive MB/HF or FR: 600 600 N/A N/A N/A N/A
Enclosure Construction: 18 mm, 13-ply birch 18 mm, 13-ply birch 18 mm, 13-ply birch 18 mm, 13-ply birch 18 mm, 13-ply birch 18 mm, 13-ply birch
Enclosure Finish: Black textured paint Black textured paint Black textured paint Black textured paint Black textured paint Black textured paint
Dimensions, Height: 801 mm (31.54 in.) 1,,007 mm (39.65 in.) 914 mm (36.00 in.) 914 mm (36.00 in.) 1,233 mm (48.54 in.) 1,233 mm (48.54 in.)
Width, Front: 455 mm (17.92 in.) 455 mm (17.92 in.) 586 mm (23.07 in.) 586 mm (23.07 in.) 586 mm (23.07 in.) 586 mm (23.07 in.)
Width, Back: 317 mm (12.48 in.) 317 mm (12.48 in.) 354 mm (13.93 in.) 354 mm (13.93 in.) 354 mm (13.93 in.) 354 mm (13.93 in.)
Depth: 463 mm (18.24 in.) 463 mm (18.24 in.) 759 mm (29.88 in.) 759 mm (29.88 in.) 759 mm (29.88 in.) 759 mm (29.88 in.)
Net Weight: 56.8 kg (125 lb) 70.3 kg (155 lb) 93.0 kg (205 lb) 93.0 kg (205 lb) 113.4 kg (250 lb) 113.4 kg (250 lb)
Full-Range Two-Way Systems Low-Frequency and Subwoofer Systems Special-Purpose Systems
System: Xi-1122/85 Xi-1152/64 Xi-1152/94 Xi-1191/Xi-1191F Sub Xi-2181/Xi-2181F LF Xi-1082 Under Balcony Xi-2122/42 Long Throw
Frequency Response: 60-20,000 Hz 50-20,000 Hz 50-20,000 Hz 37-160 Hz 37-200 Hz 50-20,000 Hz 125-20,000 Hz
(to 27 Hz in step-down)
Crossover Frequencies: 1,500 Hz 1,500 Hz 1,500 Hz 125 Hz 125 Hz 3,500 Hz (passive) 125 Hz, 1,760 Hz
Power Handling, Long Term: 300/75 W 600/75 W 600/75 W 600 W 1,200 W 175 W 600/150 W
Sensitivity (1 W/1 m), Triamp: N/A N/A N/A N/A N/A N/A N/A
Biamp/FR: 99.0/110.0 dB 98.0/113.0 dB 98.0/112.0 dB 94 dB 98.5 dB 90 dB 109.0/116.0 dB
Nominal Coverage Angle (H x V):80°x 55° 60°x 40° 90°x 40° 300°x 270° 240°x 300° 90°x 40° 40°x 20°
(long axis horizontal)
Dipole/Tripole Configurable
(with Merlin
®
ISP-100): N/A N/A N/A N/A N/A N/A N/A
Excursion-Smart Protection
(with Merlin
®
ISP-100): Yes Yes Yes Yes (with two-ways)Yes (with two-ways)No No
Transducers, LF: DL-type 12-inch EVX-155 15-inch EVX-155 15-inch EVX-180B 18-inch Two EVX-180B 18-inch 8-inch woofer
N/A
MB: N/A N/A N/A N/A N/A N/A Two-12-inch mid-bass
on mid-bass horn
HF: DH6-16 (1.4-in. exit)DH6-16/2 DH6-16/2 N/A N/A DH3 on HT94 Two ND5-16 (1.4-in.
exit)
(2.0-in. exit) (2.0-in. exit)on 60°x 40° (2.0-in. exit) on 90°x 40° 90°x 40°horn
on 40°x 20°horn on 80°x 55°horn rotatable horn rotatable horn
Impedance LF-FR/MB/HF: 8/ N/A /16 ohms 8/ N/A /16 ohms 8/ N/A /16 ohms 8/ N/A / N/A ohms
Two @ 8/ N/A / N/A ohms
8/ N/A / N/A ohms
N/A / 8/8 ohms
Connectors: Two Neutrik NL4MPRTwo Neutrik NL4MPRTwo Neutrik NL4MPRTwo Neutrik NL8MPRTwo Neutrik NL8MPRBarrier Strip Two Neutrik NL8MPR
Recommended Power Amp (watts @
8 ohms), LF/MB/HF: 600/ N/A /600 W 800/ N/A /600 W 800/ N/A /600 W 800/ N/A / N/A W 800/ N/A / N/A WN/A N/A / 800/600 W
Passive MB/HF or FR: N/A N/A N/A N/A N/A 175 W N/A
Electro-Voice X-Array
™
Xi-Series Specifications
R
®
600 Cecil Street, Buchanan, Michigan 49107, Phone: 616/695-6831, Fax: 616/695-1304
Electro-Voice, 345 Herbert St., Gananoque, Ontario, Canada K7G 2V1, Phone: 613/382-2141, Fax: 613/382-7466
Electro-Voice, A.G., Keltenstrasse 11, CH-2563 IPSACH, Switzerland, Phone: 011-41/32-51-6833, Fax: 011-41/32-51-1221
Electro-Voice, Hirschberger Ring 45, D-94302, Straubing, Germany, Phone: 011-49/9421-7060, Fax: 011-49/9421-706265
Electro-Voice, Parc de Courcerin—Allee Lech Walesa, Lognes, f-77185 Marne La Vallee, France, Phone: 011-33/1-6480-0090, Fax: 011-33/1-6006-5103
Electro-Voice, 2-5-60 Izumi, Suginami-ku, Tokyo, Japan 168, Phone: 011-81/3-3325-7900, Fax: 011-81/3-3325-7789
Electro-Voice, Unit 24, Block C, Slough Business Park, Slough Ave., Silverwater, N.S.W. 2141, Australia, Phone: 011-61/2-648-3455, Fax: 011-61/2-648-5585
Electro-Voice, Unit E & F, 21/F., Luk Hop Industrial Bldg., 8 Luk Hop St., San Po Kong, Kowloon, Hong Kong, Phone: 011-852/351-3628, Fax: 011-852/351-3329
©Telex Communications, Inc., 1999 • Litho in U.S.A. • Part Number 535036 9916
Premium touring quality sound. Install it anywhere.
A. Pro Sound Facts No. 16
part #535214-
9822
B. Special Applications Merlin
®
ISP-100
and Electro-Voice Xi-Series
™
part
#535297-9838
C. Xi-Series
™
engineering data
sheets
D. Xi-Series
™
Flying Manual
part
#534993-9825
E. ArraySHOW
™
CD
part #535290
A
B
C
D
E
F
PAGE 8
“F” suffix indicates flying configuration.
