K. Specifications
Model BC – 1230 BC – 1240 BC - 1250
Output
Absorption Charge Voltage Selections
GEL : 14.1V ; AGM: 14.3V ; WET : 14.4V ; CALCIUM-CALCIUM : 15.5V
Absorption Charge Timer
Limited not over 4hrs
Float Charge Voltage Selections
13.2V, 13.5V, 13.8V
Battery Charger / Power Supply Selections
Yes Yes Yes
Maximum Output Charging Current (Continuous)
30A 40A 50A
Recommended Battery Capacity Range
100 – 300AH 120 – 400AH 150 - 500AH
Soft Start Bulk Charge
Battery Voltage to Trigger (cut-in) Soft Start
Bulk Charge Mode
<9V
Soft Start Bulk Charge Current (Current Limit)
15A 20A 25A
Ripple and Noise (Peak to Peak)
<200mV <200mV <200mV
Efficiency at Maximum Power (100V/230V)
>83/87% >83/87% >83/87%
Dual Bank Charging (Battery must be of same type)
Yes Yes Yes
Input
AC Voltage Range
100 – 240V 50Hz~
AC Current at Full Load (100V/230V)
5.9/2.6A 7.5/3.2A 9.4/4.0A
Protection
Overload
90-110% Rated Output Current or 50% Rated Output Current (Soft Charge)
Protection Type : Constant Current Limiting, recovers Automatically after
Fault Condition is Removed.
Short Circuit
Recovers Automatically After Fault Condition is Removed
Reverse Polarity
Car Blade Fuse
Over Temperature
Protection Type: Shut Down
OVP Output Over Voltage
Yes
Cooling Cooling Method
Thermostatic, Variable Speed Fan
Indicators
3-Stage Battery Charger / Power Supply Mode
Yes
Charge Phase Bulk / Absorption / Float
Yes
Fault Mode
Yes
AC Power
Yes
Fuses
AC Fuses at IEC AC Power Socket
T6.3A T8A T10A
DC Car Blade Fuse at Front Panel
25Ax2 30Ax2 25Ax3
Accessories
Remote Temperature Sensor, Cable & Spare Fuses
Yes
Remote Control Panel
Optional
Approvals
Safety : Q061375
Yes
EMC: N2926
Yes
Others Dimensions and Weight
220x80x200mm ; 2.4kg 220x80x261mm ; 3.0kg 220x80x261mm ; 3.2kg
Remarks All values are based on the standard ambient temperature 25°C and pressure 0.1Mpa.
Rev. 2 08/2009
7673-2100-2522
