Power Requirements
Flow Requirements
Your heater is factory set to accept input water  ow entering on the left
and exiting on the right, this can be reversed by rotating the  ow switch
180 degrees (ie:½ turn, see  g 6)
WARNING! The  ow switch paddle can be damaged when reversing the  ow
direction if it is lifted by more than 5mm from its housing and turned with
force. If the  ow switch has been rotated it is important to ensure that it is
 nally locked in the correct orientation perpendicular (at right angles) to the
 ow of water.
ENGLISH
Power
Output
Voltage
(V)
Amp
2 - kW 230 9
3 - kW 230 13
4.5 - kW 230 20
6 - kW 230 27
9 - kW 230 40
12 - kW 230 53
15 - kW 230 66
18 - kW 230 79
3 Phase
Power
Output
400 V Star /
230 V Delta
Amp
6 - kW 400 / 230V 9 / 15
9 - kW 400 / 230V 13 / 23
12 - kW 400 / 230V 18 / 31
15 - kW 400 / 230V 22 / 38
18 - kW 400 / 230V 26 / 46
24 - kW 400 35
To reverse  ow: Loosen cap
and rotate Flow switch by
180 degrees as shown.
Always ensure the arrow
marked on the plastic  ow
switch body is in the same
direction as the water  ow
Factory set  ow
Optional reverse
 o w
Flow
Fig 6.
