Only for selected countries
In case of exhaust installation a window
switch might be required (consult an
authorised technician). You need to buy it
separately as it is not supplied with the
hob. The window switch has to be
installed by an authorised technician.
Refer to the installation booklet.
min.
50mm
min.
500mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
ON-TOP INSTALLATION
750-780
INTEGRATED INSTALLATION
515
515
830
830
750-780
750-780
836
521
28-43
15,5
8
ENGLISH 9
