11
Changing the decor panel
Dimensions of the panels in mm:
Model Height Width Thickness
RM 6270/71 713+/-1 453,5+1 3,2
RM 6360/61 713+/-1 453,5+1 3,2
RM 6290/91 718+/-1 491,5+1 3,2
RM 6400/01 718+/-1 491,5+1 3,2
Positioning the storage rack
To fit the storage rack, the reverse order applies.
5.10
5.11
Dismantling:
1. Open the door
and loosen the
hinge screw.
2. Take off the door
by moving it upwards.
3. Unscrew the door strip
(3 screws).
4. Remove the decor
plate and insert a new
decor plate.
5. Screw the door
strip back in
position.
6. Put the door
back on.
7. Tighten the
hinge screw.
1. Loosen the front
and back securing
brackets.
2. Move the storage rack to the left and
remove it.
2.
1.
