Electrolux E24ID74QPS - Page 25

25
Three-phase Synchronous BLDC Motor
Voltage 110-140 Vrms 46.7 Hz Power: 21 W -> resistance 46,5 ohms +/- 10% Flow rate: 3.17 – 1.32 gallons/min at 39.37 inch of head
TRIPLE BAYONET
FIXATION ALIGNED INTO
SUMP CONNECTOR
MOTOR DRIVER
(NOT INCL. IN ASSEMBLY)
POWER
SUPPLY
MOTOR
COVER
HOUSING
Voltage 120 V 60 Hz Power: 35 W -> resistance approx. 32.5 ohms Flow rate: 3.96 gallons/min at 39.37inch of head
Single Phase Synchronous Motor
