3. PRODUCT DESCRIPTION
1 2
7
4
3
5
6
9
10
11
12
8
1
Water container
2
Control panel
3
Internal light
4
Appliance door
5
Primary Filter
6
The button to open the heat
exchanger door
7
Airflow slots
8
Adjustable feet
9
Heat exchanger door
10
Heat exchanger cover
11
The knob to lock the heat exchanger
cover
12
Rating plate
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
4. CONTROL PANEL
1 2
7
3
6
5
4
8
1
Programme knob
2
Display
3
Time touchpad
4
Delay touchpad
5
Buzzer touchpad
6
Wool Load touchpad
7
Start/Pause touchpad
8
On/Off button
ENGLISH 7
