Installation manual
31
Euro mapping
Euro mapping shall only be used on machines with quick selection buttons or when rapid advance is used.
In Euro mapping there are 6 available washer signals/programs:
• Pre-wash
• Main wash
• Final rinse
• Spare 1
• Spare 2
• Spare 3
Each signal/program is capable of running up to 3 pumps.
Pumps allocated to Pre-wash will dispense the “A-amount” only. Pumps allocated to Main wash will dispense the “B-
amount” only. Pumps allocated to Final rinse, Spare 1, Spare 2 and Spare 3 will dispense the “C-amount” only.
PUMP MAPS
PRE WASH
MAIN WASH
FINAL RINSE
SPARE 1
SPARE 2
SPARE 3
