The graphic is a general
overview. For more details,
refer to other chapters or
documents provided with the
appliance.
4. CONTROL PANEL
1
2 4 5
68
3
7
1
On/off button
2
Program button
3
Programme indicators
4
Display
5
Delay button
6
Option button
7
Indicators
8
Start button
4.1 Indicators
Indicator Description
Salt indicator. It is on when the salt container needs refilling. It is al‐
ways off while the programme operates.
Rinse aid indicator. It is on when the rinse aid dispenser needs refill‐
ing. It is always off while the programme operates.
Washing phase indicator. It is on when the washing phase operates.
Rinsing phase indicator. It is on when the rinsing phase operates.
Drying phase indicator. It is on when you select a programme with the
drying phase. It flashes when the drying phase operates.
Delay indicator. It is on when you set the delay start.
