18 electrolux INSTALLING THE COOKER HOOD
EN
The cooker hood is made up of the
following components:
Ref Qty Product Components
1 1 Hood body, complete with
controls, lighting, fan and
fi lters.
2 1 Telescopic Chimney
comprising:
2.1 1 Upper section
2.2 1 Lower section
7.1 1 Telescopic frame complete
with extroctor, consisting of:
7.1a 1 Upper frame
7.1b 1 Lower frame
9 1 ø150-120 Reducer fl ange
9.1 1 ø120-125 Ducting fl ange
10 1 Flange ø150
15 1 Air outlet Connector
24 1 Junction Box
25 2 Pipe clamps
26 2 Cable clamps
27 1 Finishing plug
