35
Technical data
Model EFT 540 EFT 640 EFT 740
Airflow Max. 320 m ³/h x) 180 m ³/h 320 m ³/h x) 180 m ³/h 320 m ³/h x) 180 m ³/h
Min. 160 m ³/h 160 m ³/h 160 m ³/h
Size Height 45 mm 45 mm 45 mm
Width 498 mm 598 mm 698 mm
Depth 464 mm 464 mm 464 mm
Light Max 11 W PL Max 11 W PL Max 11 W PL
Grease filter 1 pc. 1 pc. 1 pc.
Voltage 230 V 230 V 230 V
Total power 111 W 111 W 111 W
x) Valid when the cooker hood is fitted with carbon filter.
Fig. 5
Installation
Fig. 4
Unpacking
Check that the cooker hood is not damaged.
Transportation damages should immediately be
reported to the transport company. Damages, faults
and eventually missing parts should immediately be
reported to the retailer. Dispose carefully of the
packaging material so that it is out of the way of small
children. Remove the transport supports (C-Fig. 9).
Position
The cooker hood should be mounted freely hanging on
the wall. The cooker hood must be at least 40 cm
above electric burners or electric range (Fig. 5). The
cooker hood is not approved for mounting above gas
burners or gas range.
Electrical connection
The electric outlet should be placed above the cooker
hood or inside a wall cupboard. The hood has a power
cord and moulded plug with earth connection for a
wall outlet of 230V.
Min
40
cm
