7
Installation
Installing Shelves
Your refrigerator was shipped with the shelf hanger
and shelf locking clip installed in their shipping
position. Below are the instructions to install the
shelves in your desired locations.
1 Detach clip from the back of hanger by
pushing down on the top of the clip and
pulling the clip towards you.
2 Lift the hanger directly upwards and then
towards you to remove it from the ladder.
3 Place top hooks of the hanger into the
desired slot, and lower straight down until
lower hooks rest on the ladder.
4 Reinsert clips by positioning prongs on either
side of the hanger hook and pushing down
on the top of the clip until it fits into the slot.
6 Gently set the shelf onto the hanger once the
back is secured by the hanger.
5 While holding shelf at a 45-degree angle with
the gray handle facing you, push the shelf
directing into the back of the hanger.
CAUTION
Shelves must be removed prior to moving the
refrigerator.
NOTE
Features may vary according to model.
