12
Air Filter & Luxury Design
TM
Lighting
Luxury Design™ Lighting
The interior cabinet lighting features LED
lights that gradually ramp up in intensity
after the door is opened.
To replace an LED:
1. Unplug the electrical cord or switch
OFF the power supply breaker.
2. Push down on the LED cover and then
pull away from the cabinet interior.
3. From the inside of the LED cover,
remove the wire harness connector
by pressing on the latch with a small
flat-bladed screwdriver. Pull the wire
harness connector out of the LED.
4. Replace with a new LED and install in
the reverse order.
Push on
underside of
connector to
release latch
Remove wire
harness
Pure Advantage™ Air
Filter
Your new Pure Advantage
TM
air filter is
located inside one of the 2-Liter Door Bins.
The air filter cover is located on the upper
right side of the control box. In general,
you should change the air filter with
Part Number “EAFCBF” every 6 months
to ensure optimal filtering of freezer
odors. The replacement air filter can be
purchased on the Electrolux website
(http://www.electroluxappliances.com)
or call toll free in the U.S. and Canada:
1-877-4ELECTROLUX (1-877-435-3287).
Your electronic control is equipped with a
Change Filter Indicator to remind you to
change your filter. See “Replace Air Filter”.
To Install Or Replace The Air
Filter
• Pull down on the front of the Pure
Advantage™ air filter cover. This
releases the hinged bottom cover to
drop open.
• Remove the old filter and discard it.
• Unpackage the new filter and place it
inside the hinged bottom cover of
the housing.
• Push the hinged bottom cover
upward until the tab snaps into
closed position.
replace air filter
hold to reset
press & hold
temp
mode
alarm
off
control
lock
Open air filter cover
Remove air filter
WARNING
Unplug the unit or switch the breaker
that supplies power to the unit to the off
position before changing an LED light.
