• Remove the door catch to prevent chil-
dren and pets to get closed in the ap-
pliance.
3. PRODUCT DESCRIPTION
3.1 General overview
5
4
3
2
1
6
7
8
9
1 3 4
5
2
1
Knob for the oven functions
2
Electronic programmer
3
Knob for the temperature
4
Temperature indicator
5
Knobs for the hob
6
Heating element
7
Oven lamp
8
Fan and heating element
9
Shelf positions
3.2 Cooking surface layout
170 mm
265 mm
145 mm
145 mm
140/210 mm
1 2 3
456
1
Cooking zone 1200 W
2
Steam outlet
3
Cooking zone 1500/2400 W
4
Cooking zone 1200 W
5
Residual heat indicator
6
Cooking zone 1000/2200 W
3.3 Accessories
•
Oven shelf
For cookware, cake tins, roasts.
• Combi pan
For cakes and biscuits. To bake and
roast or as a pan to collect fat.
•
Removable telescopic runners
To put shelves or trays on them.
• Storage drawer
Below the oven cavity is the storage
drawer.
ENGLISH 7
