10
Louvered Door
120 sq. Inches min.
Louvered Opening
MIN. INSTALLATION CLEARANCES -
Inches (cm)
Sides Rear Top Front
Alcove/
recess
0"
(0 cm)
0"
(0 cm)
0"
(0 cm)
Open
Closet with
door vent
0"
(0 cm)
0"
(0 cm)
0"
(0 cm)
1"
(2.5 cm)
Closet with
wall vent
1"
(2.5 cm)
1"
(2.5 cm)
1"
(2.5 cm)
1"
(2.5 cm)
Bi-Fold louvered doors with
120 sq. in of ventilation
Solid Bi-Fold doors with no
ventilation
120 sq. Inches of
wall venting
PREINSTALLATION REQUIREMENTS
