cleaning and care electrolux 35
Putting the door glass panels back.
1. From above insert the door glass
panels at an angle into the door pro-
file at the bottom edge of the door
one after the other and lower them.
Insert the smaller panel first, then
the larger panel.
2. Take hold of the door trim (B) at each
side, position it on the inside edge of
the door and plug the door trim (B)
into the upper edge of the door
On the open side of the door trim (B)
there is a guide bar (C). This must be
pushed between the outer door
panel and the guide corner (D).
The clip seal (E) must be snapped in.
