- 11 -
Spares Operation 08.01 A. B. 599 51 19 69 EN
4.5 The temperature sensor PT 500 / buzzer / devaporization opening / safety thermostat
safety thermostat
buzzer
acoustic indication lack of water
in the steam generator
(chapter 4.6)
Sound level: 75 dB( A )
devaporization opening + devaporization hose
temperature sensor PT 500
Fig.: Electrical resistance of the sensor depending on the ambient temperature
