- 5 -
Spares Operation 08.01 A. B. 599 51 19 69 EN
Touching keys for functions
1ON
2 OFF
3 child lock
4 meat probe heating
5 oven functions
6 +/- setting for temperature and time
7 cooking duration
8 switch-off time
control panel with electronic timer
oven door handle
oven door with front pane of solid glass
drawer (only in appliances with heatable
drawer)
Control panel
9 drawer heating
10 timer / minute minder
11 time of day
12 pilot lamp drawer (only in appliances with
heatable drawer)
13 water drawer
14 hot plate controller, front right
15 water drawer
The touching keys for functions are designed as push buttons with rubber caps in all appliances of the
brand Therma. With all other appliances from the list of models (chapter 1.1), these keys are designed as
touch-sensor keys.
3. Control elements
Built-in ovens
