BUILDING-IN INSTRUCTIONS
Before carrying out any work, remove the plug from
the power socket.
Door reversal
Left door opening:
1. Remove the grid from the appliance pulling it
towards you with hands.
2. Remove the left side (A) of the grid cutting it from
the rear (see figure).
To reposition the grid on the appliance proceed as fol-
lows:
Apply the grid to the base of the appliance by pushing
the clasps (a) until they click.
N.B. The grid is to be assembled after having fixed
the appliance in the niche with the brackets.
DO002
A
DO001
a
a
1
1
2
3
4
5
6
8
7
2
To reverse the opening direction of the door, proceed
as shown in the figures:
