Problem Possible cause Solution
Water flows into the re-
frigerator.
The water outlet is clogged. Clean the water outlet.
Products prevent that water
flows into the water collector.
Make sure that products do not
touch the rear plate.
Water flows on the
ground.
The melting water outlet does
not flow in the evaporative tray
above the compressor.
Attach the melting water outlet to
the evaporative tray.
The temperature in the
appliance is too low.
The temperature regulator is not
set correctly.
Set a higher temperature.
The temperature in the
appliance is too high.
The temperature regulator is not
set correctly.
Set a lower temperature.
The door is not closed correctly. Refer to "Closing the door".
The product temperature is too
high.
Let the product temperature de-
crease to room temperature be-
fore storage.
Many products are stored at the
same time.
Store less products at the same
time.
There is no cold air circulation in
the appliance.
Make sure that there is cold air
circulation in the appliance.
Replacing the lamp
1. Disconnect the appliance.
2. Push the movable part to unhook the
lamp cover (1).
3. Remove the lamp cover (2).
4. Replace the lamp with one of the same
power and specifically designed for do-
mestic appliances only.
5. Install the lamp cover.
6. Connect the appliance.
7. Open the door. Make sure that the
lamp comes on.
1
2
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
"Installation".
3. If necessary, replace the defective door
gaskets. Contact the Service Center.
TECHNICAL DATA
Dimension
Height 1540 mm
Width 595 mm
Depth 658 mm
Voltage 230 - 240 V
Frequency 50 Hz
The technical information are situated in the
rating plate on the internal left side of the
appliance and in the energy label.
electrolux 19
