mm . Ideally, however, the appliance
should not be positioned below
overhanging wall units. Accurate levelling
is ensured by one or more adjustable
feet at the base of the cabinet.
9.5 Door reversibility
WARNING!
Before carrying out any
operations, remove the plug
from the power socket.
CAUTION!
To carry out the following
operations, we suggest that
this be made with another
person that will keep a firm
hold on the doors of the
appliance during the
operations.
1. Unscrew both screws on the rear
side.
2. Push back the top and lift it.
3. Unscrew the left foot.
4. Unscrew the screws of the door
bottom hinge. Remove the hinge. Put
over the pin in the direction of the
arrow.
5. Unscrew and install the screw on the
opposite side.
6. Install the hinge on the opposite side.
7. Screw the right foot.
8. Unscrew the screws of the door top
hinge.
www.electrolux.com12
