Electrolux ERW1573AOA - Installation Dimensions (MM) And Ventilation Requirements

11
ENGLISH
INSTALLATION
INSTALLATIONDIMENSIONS(MM)ANDVENTILATION
REQUIREMENTS
Dimensions
Overalldimensions
1)
H1 mm 820
W1 mm 595
D1 mm 565
1)theheight,widthanddepthofthe
appliancewithoutthehandle.
Overall space required in use
1)
H2 mm 822
W2 mm 600
D2 mm 648
1)theheight,widthanddepthofthe
appliancewiththehandle,plusthehandle
forfreecirculationofthecoolingair.
Overall space required in use
1)
H3 mm 820
W3 mm 648
D3 mm 1157
1)theheight,widthanddepthofthe
appliancewiththehandle,plusthehandle
for free circulation of the cooling air,plus
thespacenecessarytoallowdoor
openingtotheminimumanglepermitting
removalofallinternalequipment.
