1. Water hardness adjustment
2. Levelling spacers
3. Upper basket stop
4. Salt container
5. Large filter
6. Detergent dispenser
7. Control panel
8. Rating plate
9. Rinse aid dispenser
10. Central filter
11. Lower spray arm
12. Upper spray arm
13. Upper basket
14. Worktop
1. On/Off indicator light
2. On/Off push button
3. Main wash temperature push
button (50°)
4. Programme guide
5. Door handle
6. Salt refilling indicator light
(See “Instruction book” - part 1)
7. Programme selector dial
8. Programme sequence indicator
As the programmes progresses, the programme dial
turns, to show the phase in the wash programme the
appliance has reached.
Prewash /Rinse and hold
Wash
Cold rinse
Hot rinse
Drying
7
Description of the appliance
The control panel
