The control panel
4
On/Off
push button
Door handle
On/Off
indicator light
Programme
selector dial
Programme
guide
Programme
sequence
indicator
Programme sequence indicator: as the programme
progresses, the programme selector dial turns, to show the
phase in the wash programme the appliance has reached.
Prewash / Rinse and Hold
Main wash
Cold rinse
Hot rinse
Drying
1. Upper basket stop
2. Water hardness switch
3. Salt container
4. Detergent dispenser (type A / type B)
5. Control panel
6. Rating plate
7. Rinse aid dispenser (type A / type B)
8. Filters
9. Lower spray arm
10. Upper spray arm
11. Upper basket
12. Worktop
Description of the appliance
