33
Connecting systems
The water inlet hose, drain hose and the mains cable
must all be connected to the side of the dishwasher
as there is no space for them behind the appliance.
2 connection pieces 45° or straight,
outer ø 19 mm, length 30 mm
doublevalve water-
drainage
waterinlet
waterinlet mains
cable
water-
drainage
mains socket mains cable
