Electrolux EU8297CX - Description of the Appliance; Control Panel

3
Electrolux 818 15 86-01/0
Description of the Appliance
GB
1
2
2
4
2
2
2
3
Model EU8297CX
1. Freezer plate
2. Freezer drawer
3. Ventilation grille
4. Freezer calendar
2
Control Panel
*
-- 1 8
ACTION FREEZE
ABCDEFG
A. Freezer power switch
Switches the freezer on and of f.
B. Temperature display
Shows the highest temperature inside the freezer.
C. Temperature adjustment buttons/thermostat
Used to set the temperature in the freezer.
D. FAST FREEZE button
Used to switch the fast Freeze feature on and off.
E. Yellow indicator lamp
Lights when fast Freeze is operating.
F. Alarm shut-off button
Used to turn the audible alarm off.
G. Red warning lamp
Flashes when one of the alarms in the cabinet has
been triggered.
