FF IINNSSTTAALLLLAATTIIOONN AANNDD AASSSSEEMMBBLLYY
FF..11 IInnttrroodduuccttiioonn
To ensure correct operation of the appliance and maintain
safe conditions during use, carefully follow the instructions
given below in this section.
WWAARRNNIINNGG
The above operations must
be carried out by the
specialised technician in
conformity with the current
safety regulations, regarding
the equipment used and the
operating procedures.
Before moving the appliance
make sure the capacity of
the lifting equipment used is
suitable for its weight.
FF..22 CCuussttoommeerr rreessppoonnssiibbiilliittiieess
The Customer must provide for the following:
• installation of an adequate electrical power supply ahead
of the appliance, according to the equipment’s technical
specifications (D.1
Main technical characteristics
and D.2
Characteristics of power supply
);
• the equipotential connection of the workplace electrical
system to the metal structure of the machine by means of a
copper cable of adequate section (see position “EQ“ in
Installation diagram
);
• adducting for the electrical connection between the
workplace electric panel and the equipment;
• the water supply and drain connections and other
connections as indicated in D.1
Main technical
characteristics
and in the paragraph F.6
Plumbing
connections
.
FF..33 CChhaarraacctteerriissttiiccss ooff tthhee iinnssttaallllaattiioonn ppllaaccee
The machine is designed for installation in professional and
not domestic-type kitchens. Water collection traps/ metal
grates must be arranged in the floor at the machine
discharges (see the
Installation diagram
), possibly
replaceable with a single water trap sized for a flow rate of at
least 3 l/s.
CCAAUUTTIIOONN
Do not install the appliance over 2000
meters above sea level.
FF..44 PPoossiittiioonniinngg
The machine must be taken to the place of installation and
the packing base removed only when being installed.
Arranging the machine:
• Wear protective gloves and unpack the machine.
• Lift the equipment with a lift truck, remove the base and
position it the place of use.
• Carefully remove the protective film from the outer panels
without tearing it, to avoid leaving traces of glue.
• Adjust the equipment by turning the special adjustable feet
and making sure it is perfectly level, both length wise and
crosswise.
