24
II CCOONNTTRROOLL PPAANNEELL
II..11 CCoonnttrrooll ppaanneell ddeessccrriippttiioonn
LLEEGGEENNDD
1 on/off
2 drain/self-cleaning cycle
3 display
4 tank temperature indicator
5 boiler temperature indicator
6 wash cycle 1
7
wash cycle 2
8 regeneration cycle
NOTE!
The temperature shown on the display refers to the
boiler if the indicator “5“ is lit up or to the tank, if the
indicator “4“ is lit up.
The tank temperature is displayed during the wash
phase and the boiler temperature during the rinse
phase.
II..22 BBaassiicc CCoonnttrroollss
Described below are all the single buttons and functions
available in the various control panel models listed above.
Some functions are common to all models of the range,
whereas others are available only on some versions.
OOnn//OOffff
This button indicates equipment status: on or off. When the
equipment is on, the button indicator is lit up.
RReeggeenneerraattiioonn ccyyccllee
When on the display appears “rEG“, press this button to
activate the regeneration cycle of the water continuous
softener.
DDrraaiinn // sseellff--cclleeaanniinngg ccyyccllee
This button starts a drain/self-cleaning cycle. When the cycle
is selected, the button indicator is lit up.
WWaasshh ccyyccllee 11
This button starts WWaasshh ccyyccllee 11. When the cycle is selected,
the button indicator is lit up. This cycle is recommended for
washing not very dirty dishes.
WWaasshh ccyyccllee 22
This button starts WWaasshh ccyyccllee 22. When the cycle is selected,
the button indicator is lit up. This cycle is recommended for
washing normally dirty dishes.
