4.4 Removal of freezing baskets and glass shelves from the freezer
2
1
Some of the freezing baskets have a limit
stop to prevent their accidental removal or
falling out. At the time of its removal from
the freezer, pull the basket towards your-
self and, upon reaching the end point, re-
move the basket by tilting its front up-
wards
At the time of putting it back, slightly lift
the front of the basket to insert it into the
freezer.
Once you are over the end points, push
the basket back in their position.
1
2
1
The appliance is equipped with shelf
stops to secure the shelves.
The shelves must be lifted up (1) on each
side and than pulled outwards (2).
The glass shelves equipped with expand-
er rollers are secured with locking pins.
2
1
1
1
To remove them proceed as follow:
1.
Use a screwdriver to loosen the lock-
ing pin on each side on the expander
roller.
2.
Then pull out both locking pin (1).
3.
Then pull the glass shelf outwards (2).
5. HELPFUL HINTS AND TIPS
5.1 Hints for freezing
To help you make the most of the freezing
process, here are some important hints:
• the maximum quantity of food which
can be frozen in 24 hrs. is shown on
the rating plate;
• the freezing process takes 24 hours.
No further food to be frozen should be
added during this period;
• only freeze top quality, fresh and thor-
oughly cleaned, foodstuffs;
ENGLISH 9
