Electrical connection
This machine is designed to operate on a 220-
230 V, single-phase, 50 Hz supply.
Check that your domestic electrical installation
can take the maximum load required (2.25 kW),
also taking into account any other appliances in
use.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manufacturer declines any liability
should this safety measure not be
observed.
The appliance is supplied with a 13amp plug
fitted.
In the event of having to change the fuse in the
plug supplied, a 13amp ASTA approved
(BS1363A) fuse must be used.
Should the plug need to be replaced for any
reason, proceed as described below.
The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
The wire coloured green and yellow must be
connected to the terminal marked with the letter
«E» or by the earth symbol or coloured
green and yellow.
The wire coloured blue must be connected to
the terminal «N» or coloured black.
The wire coloured brown must be connected to
the terminal marked «L» or coloured red.
Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must
be secure over the outer sheath.
WARNING:
A cut off plug inserted into a 13 amp
socket is a serious safety (shock)
hazard.
Ensure that the cut off plug is disposed
of safely.
GREEN & YELLOW
BROWN
CORD CLAMP
BLUE
13A
P1041
E
N
L
