Electrolux EW2F4822BF - Control Panel Description; Display Overview

6.2 Control panel description
1 2 3 4
910
7
6
8
5
1
Programme knob
2
Centrif. reduction touchpad
3
Temp. touchpad
4
Display
5
Pre-lav. touchpad
6
Inicio Diferido touchpad
7
Extra Aclarado /Enxag. touchpad
8
Fácil touchpad
9
Inicio/Pausa touchpad
10
Time Manager touchpads
6.3 Display
A B
E D
C
A. The time area:
• Programme time.
• The alarm codes. Refer to the
chapter “Troubleshooting” for their
description.
• The level of the Time Manager
.
B. The Delay Start indicator.
C. The Child Lock indicator.
D. The Door Lock indicator:
• It is on, you cannot open the door.
• It is off, you can open the door.
• It flashes, you cannot open the
door. Wait for some minutes until
the indicator is off.
E. Washing phase indicators.
• : the washing phase
• : the rinses phase
•
: the spin phase
