6. Position the hose directly to a built-in
drain pipe in the room wall and tighten
it with a clamp.
4. PRODUCT DESCRIPTION
4.1 Appliance overview
1
Worktop
2
Detergent dispenser
3
Control panel
4
Door handle
5
Rating plate
6
Drain pump filter
7
Feet for levelling the appliance
8
Drain hose
9
Inlet hose connection
10
Mains cable
11
Transit bolts
12
Hose support
5. CONTROL PANEL
5.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
respectful of fabric care.
• The steam has a quick and easy way
to refresh the clothes. The gentle
steam programmes remove odours
and reduce creases in dry fabrics so
they need little ironing.
• Thanks to the Jemné+ option, the
fabric softener is uniformly spread out
in the laundry and deeply penetrates
ENGLISH 9
