Programme Chart
Various programme charts in different lan-
guages are supplied with the appliance. One
is on the front side of the detergent dispenser
drawer and the others are attached into the
user manual assy. The chart in the drawer
can be replaced easily: remove the chart
from the drawer by pulling it towards the right
and insert the chart with the language re-
quired.
Control panel
Below is a picture of the control panel. It shows the programme selector dial as well as
the temperature selector dial, the buttons and the pilot lights. These are presented by
relevant numbers on the following pages.
1
PROGRAMME selector dial
2
TEMPERATURE selector dial
3
SPIN reduction button
4
OPTIONS button
5
EXTRA RINSE button
6
START/PAUSE button
7
DELAY START button
8
Pilot Lights
Table of Symbols
Programme selector dial
= Cottons = Soak
= Synthetics = Mini 30
= Easy iron = Rinses
= Delicates = Delicate rinses
= Wool = Drain
= Handwash = Spin
= Silk = Delicate spin
Temperature selector dial and buttons
= Temperature = Options button
electrolux 5
