Electrolux EWF10746 - CONTROL PANEL; Control Panel Description; Display

ENGLISH 9
CONTROL PANEL3.
Program Knob
3.1 Control Panel Description
1
1
Temperature Touchpad
2
Spin Selection Touchpad
3
Display
4
Child Lock (see page 12)
5
Rinse Plus Touchpad
6
Delay End Touchpad
7
Easy Iron Touchpad
8
Prewash Touchpad
9
Add Clothes Function Symbol
10
Start/Pause, Add Clothes Touchpad
11
Time Manager Touchpad
12
Vapour Touchpad
13
2 3 4 65
7
8
9
10
111213
3.2 Display
Digital Number;
will tell you:
The level of the Time Manager ( ).
-
Washing cycle time.
-
-
The alarm codes. Refer to the chapter
“Troubleshooting” for their description.
-
Delay End time.
-
It is on, you cannot open the door.
-
It is off, you can open the door.
Max. Spin
Model EWF10746: 1000 rpm
Model EWF12746: 1200 rpm
B
C
D
A
A
B
C
F
E
D
Delay End Icon
Child Lock Icon
Door Lock Icon
Vapour Icon
Washing Phase icon (Wash/Rinse/Spin)
EF
